18V Solar Panel 100w Panel Solar Battery Charger Solar Power for Outdoor Camping Mobile RV 12V battery charger
18V Solar Panel 100w Panel Solar Battery Charger for Outdoor Camping Mobile RV 12V battery charger
Advanced encapsulation material with multi-layer sheet metal laminations to improve cell performance and guarantee a long service life.
Bypass diodes minimize the drop in performance caused by shadows and ensure excellent performance in low light conditions.
Positive tolerance guarantee (0-3%); Withstand high wind (2400Pa) and snow loads (5400Pa) and the IP65 junction box offers complete protection against environmental influences and low-pressure water jets.
Corrosion-resistant aluminum frame for extended outdoor use so the solar panels can last for years.
Specification:
Maximum power(Pmax) 100W
Output tolerance ± 5%
Maximum system voltage 1000V DC
Open circuit voltage(Voc) 23.76V
Short circuit current(Isc) 5.55A
Maximum power voltage(Vmp) 19.8V
Maximum power current(Imp) 5.05A
Cell efficiency 23%
Operating temperature(NOCT) 45±2℃
Temperature range -40℃～+80℃
Cell Monocrystalline silicon
Weight 4085g
Size 955*530*25 mm OR 1050*530*25MM
Surface material PET
Standard Test Conditions : lrradiance 1000w/m^2, Temperature 25℃, AM=1.5
Buyers please note: there are two sizes of PET solar panels, if not specifically indicated, the order will be shipped randomly, the same order will be sent the same size solar panels
1pcs 100W Package list
1 * 100w PET solar panel
19.8V 100W Package list
1 * 100w PET solar panel
