220v 1kwh solar panels complete kit 12 volts 110V 1000W Inverter + 200 Watt Photovoltaic Panel + cable + Controllers
220v 1kwh solar panels complete kit 12 volts 110V 1000W Inverter + 200 Watt Photovoltaic Panel + cable + Controllers
*Package list:
2 * 100w solar panel
1*12v/24v 20Acontroller
1* 3meters 2.5mm² PV cable
1* 3meters 2.5mm² alligator clips
1* 2 in 1 Connector
1 * 12V to 110V or 12V to 220V 1000W Inverter
eatures:
treated with a special process, which is more wear-resistant and
improves the absorption efficiency of sunlight.
waterproof design, which includes a bypass diode, and the circuit adopts
input overcurrent protection and reverse protection design.
modules are used for outgoing cables. The outdoor use is safe,
waterproof, high temperature resistance and weather resistance. pv
connectors are easy to use, plug and play.
is recommended to be used with controllers and batteries. It can be used
in a variety of scenarios such as RVs, households, camping, yachts,
street lights and solar power stations.
Specification of 100w
*Notes:
(1) This product must not come into contact with highly corrosive substances.
(2) It is strictly forbidden to drop and hit the junction box and products by yourself, avoid stepping on the surface and scratching the surface with hard objects during use.
(3) A large number of scratches or dirt on the surface of the solar panel may cause the solar cell module to be inefficient, and in severe cases may cause burnout.
(4) The solar panel must be installed in an area with good sunlight and no shadow. The long-term work of the solar cell module in the sun with shadow may have the risk of burning.
(5) It is forbidden to connect the positive and negative poles of the product together, and it is forbidden to put the product into water or fire, otherwise it will damage the product.
(6) The overall power of the photovoltaic module must be less than the rated power of the controller (rated voltage × rated current). It is strictly prohibited to overload the controller.
(7) The total voltage of the photovoltaic module connected to the controller must be within the photovoltaic input voltage range of the controller.
(8) The controller must be connected with battery first. The controller is used to protect the battery from overcharge and discharge. And if you use the power inverter, the inverter can only be connected to the battery, not directly to the controller.
(9)The current and voltage parameters of solar panels are tested under standard test conditions. If the sunshine intensity and time are not enough, the power and current cannot reach the standard data.
*Attention:
(1) Please do not use the PO BOX address when you place the order. In many cases, the logistics company cannot deliver the PO BOX normally.
(2) In addition, the shipping ways we choose do not include customs clearance and tariff payment.
(3) Please ensure that your phone and address information is accurate and valid. When the logistics delivers the package, the invalid phone number and address will affect the transportation and delivery.
(4) If you have any question about the order, you can contact with us in time. We will solve it for you as soon as possible.
Spain,When you buy it,if you are in EU,we will ship to your country that
you don't need to consider customs clearance and duties and it will be
fast delivery.
The inverter is controlled by the company's intelligent CPU, and its circuit has applied for a patent and has passed CE certification.Using high-quality double-sided circuit boards and components to ensure high quality and high performance.The output waveform of this machine is pure sine wave, which can be applied to any load.with very perfect
Protection functions (including overload protection, overcurrent protection, high temperature protection, short circuit protection, battery reverse connection protection, battery high and low voltage protection, built-in fuse, etc.). The size of this machine is very small and easy to carry.
Scope of application: outdoor, vehicle, power outage, solar energy, wind energy, other occasions where AC power (110V / 220VAC) is required in the home
5. Input Features:
5.1 Rated input voltage: 12VDC
5.2 Input voltage range: 10-16VDC
5.3 Standby input power: <25W
6. Output characteristics:
6.1 Rated output power: 1000W
6.2 Peak output power: 2000W
6.3 Output voltage: 110V/220VAC±10%
6.4 Output frequency: 50Hz 60HZ±3Hz
6.5 Output waveform: sine wave
7. Actual power: 1000W
8. Protection features:
8.2 Input low voltage protection: 9V±0.2V
8.3 Input high voltage protection: 17V
8.4 Low input voltage alarm: 9V
8.5 Output overload and >1200W protection time: 30 seconds
8.6 Output short circuit protection time: 2 to 3 seconds
8.7 Output heavy load (>1300W) protection time: 2 to 3 seconds
8.8 Temperature protection: >70℃
9. Status indication:
9.1 Indication of normal work: the green light is always on
9.2 Input voltage abnormal indication:
Input low voltage alarm Red light flashes
Input low voltage protection red light
Input high voltage protection red light
9.3 Output abnormal indication:
Output overload Lights up yellow
Output overload and short-circuit protection After the output is overloaded or short-circuited for 2 to 3 seconds
9.4 Abnormal temperature indication: yellow light
10. Interface specification:
10.1 Input terminal specification: Φ6mm binding post (one for red and one for black)
10.2 Specification of output socket: three-hole socket
10.3 Power switch: 1
11. Insulation properties:
11.1 Insulation withstand voltage:
Input to output 1000VAC (50Hz 1 minute ≤1.5mA)
Input to shell 1000VAC (50Hz 1min ≤1.5mA)
Output to shell 1000VAC (50Hz 1min ≤1.5mA)
11.2 Insulation resistance:
Input to output >20MΩ(1000VDC)
Input to case >20MΩ(1000VDC)
Output to case >20MΩ(1000VDC)
12. Mechanical properties:
Size Specifications: 320X150X70MM
Weight 3.35KG
Housing material Aluminum profile
13. Temperature characteristics
Storage temperature -20~+80℃
Working environment temperature -20~+60℃
Cooling method Air cooling
