Glass Solar Panel 50W 100W 25 Years Service Life 25MM Thickness Aluminum Frame Cell 12V 19.8V Rigid Tempered Photovoltaic panels
25 Years Service Life 25MM Thickness Aluminum Frame Glass Solar Panel 50W 100W Cell 12V 19.8V Rigid Tempered Photovoltaic panels
19.8V 50W Solar Panel specifications
Maximum power(Pmax) 50W
Output tolerance ± 3%
Maximum system voltage 1000V DC
Open circuit voltage(Voc) 23.76V
Short circuit current(Isc) 2.77A
Maximum power voltage(Vmp) 19.8V
Maximum power current(Imp) 2.52A
Cell efficiency 24%
Operating temperature(NOCT) 45±2℃
Temperature range -40℃～+80℃
Cell Monocrystalline silicon
Number of cells 36pcs
Weight 3500g
Size 810*360*25mm
Surface material Toughened glass
Back film Color White
Output port 0.5 m long MC 4 connector wire
Standard Test Conditions : lrradiance 1000w/m^2, Temperature 25℃, AM=1.5
OR
18V 50W
Maximum power(Pmax) 50W
Output tolerance ± 3%
Maximum system voltage 1000V DC
Open circuit voltage(Voc) 21.6V
Short circuit current(Isc) 3.05A
Maximum power voltage(Vmp) 18V
Maximum power current(Imp) 2.77A
Cell efficiency 19.5%
Operating temperature(NOCT) 45±2℃
Temperature range -40℃～+80℃
Cell Monocrystalline silicon
Number of cells 36pcs
Weight 3300g
Size 680*510*25 mm
Surface material Toughened glass
Back film Color White
Output port 0.5 m long MC4 connector wire
Standard Test Conditions : lrradiance 1000w/m^2, Temperature 25℃, AM=1.5
Package included:
1 x 50W glass solar panel (50W)
or
1 x 50W glass solar panel (50W Kit A)
1 x 10A 12V/24V Controller
1 set 3m cable with PV connector
1 set 3m cable with Alligator clip
or
1 x 50W glass solar panel (50W Kit B)
1 x Waterproof 10A 12V/24V Controller
1 set 3m cable with PV connector
1 set 3m cable with Alligator clip
Features:
1. The surface is made of Toughened glass, which is more wear-resistant and improves the absorption efficiency of sunlight.
2. With high light transmittance, safe and reliable, not afraid of high temperature, no danger of burning or explosion.
3. The junction box adopts IP65 waterproof design, contains bypass diode, and the circuit adopts overcharge and r
