PowMr MPPT 60A Solar Charge Controller Discharge Backlight 12V 24V 36V 48V Auto for Vented Sealed Gel Nicd Li Solar Cells Panel
PowMr MPPT 60A Solar Charge Controller Discharge Backlight 12V 24V 36V 48V Auto for Vented Sealed Gel Nicd Li Solar Cells Panel
Overview:
This is a powerful and high-quality solar charger. You can charge various types of batteries and automatically identify the battery voltage. Simple operation, suitable for individuals, families, agriculture and animal husbandry.
MPPT 60A This machine uses MPPT point tracking technology, MPPT series solar charge controller is based on an advanced maximum power point tracking(MPPT) technology developed,dedicated to the soalr system,the charge controller conversion efficiency up to 97%.
Featrues:
❶MPPT 60A solar charge controller.
❷100% MPPT technology.
❸Built-in DSP controller with high performance.
❹Automatic switch for 12V/24V/36V/48Vbattery bank.
❺3-stage charging optimizes battery performance.
❻Overcharge protection, Input PV polarity reverse protection, Output limited current protection, ver-temperature protection.
❼Troubleshooting promotion function.
❽Suitable for battery types such as sealed lead acid, vented gel and lithium battery, etc.
❾Easy to be mounted.
Notes:The output terminal is for lamp only( 12V system less 60W, 24V/36V/48V system less 100W ),and it will be burnt if connecting to other loads. The output for battery is no polarity reverse protection.
Specification:
Model | 60A |
Charging mode | MPPT Maximum power point tracking automatically |
Charging | 4-stage: constant current(MPPT), constant voltage(Absorption Voltage), floating charge, bulk charge |
System type | DC12V/24V/36V/48V Recognition automatically |
System voltage automatic | 12V system (DC9V-DC15V) /24V system (DC18V-DC29V) /36V system (DC30V-DC39V) 48V system (DC40V~DC60V) |
recognition | |
Soft start time | ≤1S |
Dynamic response and recovery time | 100us |
Max efficiency | ≥98.1% (Voc is 1.5 or 2 times than battery, then it's best efficiency) |
PV utilization | ≥99% |
Input specification | |
Voc from PV( Make sure the Voc of PV meeting the requirement as right. Voc is 1.5 or 2 times than battery, then it's best efficiency. ) | 12V system (DC20V~DC80V) 24V system (DC37V~DC105V) |
36V system (DC50V~DC160V) 48V system (DC72V~DC160V) | |
maximum PV input voltage (Voc) | 160VDC |
The maximum PV input power | 12V system (720W) |
(The total power rated of PV can't be over this watt that will break the controller.) | 24V system (1440W) |
36V system (2100W) | |
48V system (2800W) | |
Output specification | |
