MPPT 60A 12V 24V 36V 48V Auto LCD Display Solar Charger Controller Solar Panel Batteries Charge Regulator EU RU US Warehouse
MPPT 60A 12V 24V 36V 48V Auto LCD Display Solar Charger Controller Solar Panel Batteries Charge Regulator EU RU US Warehouse
100% MPPT controller
Intelligent Maximum Power Point Tracking technology
Built-in DSP controller with high performance
Automatic battery voltage detection 12V/24V/36V/48V
Three-stage charging optimizes battery performance
Multi-function LCD displays
Reverse polarity protection of solar panel
Overcharge protection
Can be mounted easily
Suitable for battery types of sealed lead acid, vented Gel, and Lithium battery
Notes: The output terminal is for lamp only ( 12V system less 60W, 24V/36V/48V system less 100W ),and it will be burnt if connecting to other loads. The output for battery is no polarity reverse protection.
Package Include
1 PCS MPPT Solar Controller
1 PCS English User Manual
Model No. | MPPT-60A |
Charging mode | MPPT Maximum power point tracking automatically |
Charging | 3-stage:constant current(MPPT), constant voltage(Absorption Voltage), floating charge |
System type | DC12V/24V/36V/48V Recognition automatically |
System voltage automatic recognition | 12V system (DC9V-DC15V) |
24V system (DC18V-DC29V) | |
36V system (DC30V-DC39V) | |
48V system (DC40V~DC60V) | |
Soft start time | ≤1S |
Dynamic response and recovery time | 100us |
Max efficiency | ≥98.1% (Voc is 1.5 or 2 times than battery, then it's best efficiency) |
PV utilization | ≥99% |
Input specification | |
Voc from PV ( Make sure the Voc of PVmeeting the requirement as right. Voc is 1.5 or 2 times than battery, then it's best efficiency. ) | 12V system (DC20V~DC80V) |
24V system (DC37V~DC105V) | |
36V system (DC50V~DC160V) | |
48V system (DC72V~DC160V) | |
The maximum PV input voltage (Voc) | DC190V(The controller can't work at this voltage of long duration that will break controller. Please refer to Input voltage from PV.) |
The maximum PV input power (The total power rated of PV can't be over this watt that will break the controller.) | 12V system (720W) |
24V system (1440W) | |
36V system (2100W) | |
48V system (2800W) | |
Output specification | |
Selectable battery type(default is Sealed) | Vented/ Sealed / Gel / NiCd / Lithium battery(defined voltage for other battery by user) |
Absorption Charging Voltage | Refer to Batteries charging reference |
Floating Charging Voltage | |
Overcharging protection voltage | 12V system (15V) |
24V system (30V) | |
36V system (45V) | |
48V system (60V) | |
Rated output current | 60A |
Temperature Coefficient | ±0.02%/ centi-degree |
utomatic temperature compensation | 14.2V-(Max temperature-25 centi-degree)*0.3 |
Output voltage ripple-peak | 100mV |
Output voltage accurac | ≤±1% |
Input Anti-intrusion protection | yes |
Temperature Protection | 75°C |
Temperature increased protection | Output power will reduce when it's more 70 °C Output power will be normal when it's less 55 °C |
Fan-on temperature | >40 °C |
Fan-off temperature | <35 °C |
Acoustic noise | ≤40dB |
Cooling way | Forced air cooling. |
Components | Imported materials, Accord to EU standards, Industrial grade range. |
Environmental requirements | Meet 2002/95/EC; No cadmium, hydrides and fluorides |
Security Level | Accord to CE, PSE, FCC, EMC, EN60950 |
Electromagnetic Compatibility | Accord to EN61000, EN55022, EN55024 |
Enclosure | IP21 |
[Software Update MPPT Design ]100% MPPT 60A solar charge controller Intelligent, Max efficiency ≥98.1%, PV utilization ≥99%. Built-in DSP controller with high performance Automatic battery voltage detection 12V/24V/36V/48V, Make sure batteries' voltage more than 12V to boost controller and make sure battery has enough power to Self-detection when connected to the controller.
[Full System Protection]Backlight LCD Dispaly PV voltage/output power/Battery voltage/charging current/working mode/Temperature. ☀ TROUBLESHOOTING function and LCD display and can help users not only check the whole system operating data and statuses but also quickly identify system faults and modify parameters.
